4.1) 106 Mhz

4.2) 8.17 Mhz

The circuit to the right is an NMOS common source amplifier. Assume V_A = infinity, gm = 0.5mmho, Cgs = 3pF, and Cgd = 1.5pF. At what frequency in Hz is the pole due to Cgs? Pole from Cgs = At what frequency in Hz is the pole due to Cgd? Pole from Cgd

Pole from cgs=1/(2*pi*Cgs*gm)=1/(2*pi*3p*0.5m)=106Mhz

Pole from cgd=1/(2*pi*Cgd*gm)=1/(2*pi*1.5p*0.5m)=8.17Mhz
