match the following attributes to the parts of a compiler st

match the following attributes to the parts of a compiler

strips out the comments and whitespace

converts text into lexemes

generates an Abstrat Symbol Tree

recursive descent or table driven

uses BNF or EBNF definitions

a. lexer

b. parser

Solution

The Program and Portfolio Management Maturity Model is an effective tool for organizations to decide quickly what PPM improvements they should make to enhance their organization\'s ability to optimize investments, execute big changes and deliver value.

Overview
Key Findings
Real project, program and portfolio management, when operating at the level of well-integrated practices, is the key enabler that allows organizations to identify and execute strategic change.

Any meaningful undertakings to enhance or evolve the program and portfolio management (PPM) function must pay more than lip service to organizational structure, business model and culture to have any chance of success.

Competitive pressures and changing market conditions are forcing organizations toward Level 3, and most organizations still aren\'t ready to make the leap.

Recommendations
At any level of PPM maturity, focus first on helping the organization make well-informed investment choices. This will improve the odds of project success more than any other factor.

For organizations that require enterprisewide change and capabilities, it is worth the effort to pursue Level 4, where enterprise PPM practices are built.

Identify objectives for your enterprise, and use them to identify the most salient improvement opportunities for your enterprise.

Meticulously manage the change involved in maturing/improving your PPM capabilities.

Analysis
Project/program/portfolio management office (PMO) leaders, program managers and portfolio managers are frequently challenged by ineffective processes, lack of stakeholder engagement and difficult-to-quantify value. 1 Part of the problem is failure to match their processes, people and technology approaches to the maturity level of their organizations. 2

The Gartner Program and Portfolio Management (PPM) Maturity Model assessment is designed to help PPM leaders understand best practices around large project management, as well as PPM to handle delivery of strategic value. This model assumes that organizations progress through a maturity curve and that each level of organizational maturity directly affects the level of investment and types of PPM approaches organizations choose to adopt.

arsing

A parser is an algorithm that determines whether a given input string is in a language and, as a side-effect, usually produces a parse tree for the input. There is a procedure for generating a parser from a given context-free grammar.

Recursive-Descent Parsing

Recursive-descent parsing is one of the simplest parsing techniques that is used in practice. Recursive-descent parsers are also called top-down parsers, since they construct the parse tree top down (rather than bottom up).

The basic idea of recursive-descent parsing is to associate each non-terminal with a procedure. The goal of each such procedure is to read a sequence of input characters that can be generated by the corresponding non-terminal, and return a pointer to the root of the parse tree for the non-terminal. The structure of the procedure is dictated by the productions for the corresponding non-terminal.

The procedure attempts to \"match\" the right hand side of some production for a non-terminal.

To match a terminal symbol, the procedure compares the terminal symbol to the input; if they agree, then the procedure is successful, and it consumes the terminal symbol in the input (that is, moves the input cursor over one symbol).
To match a non-terminal symbol, the procedure simply calls the corresponding procedure for that non-terminal symbol (which may be a recursive call, hence the name of the technique).
Recursive-Descent Parser for Expressions

Consider the following grammar for expressions (we\'ll look at the reasons for the peculiar structure of this grammar later):

<E> --> <T> <E*>
<E*> --> + <T> <E*> | - <T> <E*> | epsilon
<T> --> <F> <T*>
<T*> --> * <F> <T*> | / <F> <T*> | epsilon
<F> --> ( <E> ) | number
We create procedures for each of the non-terminals. According to production 1, the procedure to match expressions (<E>) must match a term (by calling the procedure for <T>), and then more expressions (by calling the procedure <E*>).

procedure E;
   T; Estar;

Some procedures, such as <E*>, must examine the input to determine which production to choose.

procedure Estar;
   if NextInputChar = \"+\" or \"-\" then
   read(NextInputChar);
   T; Estar;

We will append a special marker symbol (ENDM) to the input string; this marker symbol notifies the parser that the entire input has been seen. We should also modify the procedure for the start symbol, E, to recognize the end marker after seeing an expression.

Top-Down Parser for Expressions

procedure E;
   T; Estar;
   if NextInputChar = ENDM then /* done */
   else print(\"syntax error\")

procedure Estar;
   if NextInputChar = \"+\" or \"-\" then
   read(NextInputChar);
   T; Estar;

procedure T;
   F; Tstar;

procedure Tstar;
   if NextInputChar = \"*\" or \"/\" then
   read(NextInputChar);
   F; Tstar;

procedure F;
   if NextInputChar = \"(\" then
   read(NextInputChar);
   E;
   if NextInputChar = \")\" then
       read(NextInputChar)
   else print(\"syntax error\");
   else if NextInputChar = number then
       read(NextInputChar)
   else print(\"syntax error\");


BNF is sort of like a mathematical game: you start with a symbol (called the start symbol and by convention usually named S in examples) and are then given rules for what you can replace this symbol with. The language defined by the BNF grammar is just the set of all strings you can produce by following these rules.

The rules are called production rules, and look like this:

symbol := alternative1 | alternative2 ...
A production rule simply states that the symbol on the left-hand side of the := must be replaced by one of the alternatives on the right hand side. The alternatives are separated by |s. (One variation on this is to use ::= instead of :=, but the meaning is the same.) Alternatives usually consist of both symbols and something called terminals. Terminals are simply pieces of the final string that are not symbols. They are called terminals because there are no production rules for them: they terminate the production process. (Symbols are often called non-terminals.)

Another variation on BNF grammars is to enclose terminals in quotes to distinguish them from symbols. Some BNF grammars explicitly show where whitespace is allowed by having a symbol for it, while other grammars leave this for the reader to infer.

There is one special symbol in BNF: @, which simply means that the symbol can be removed. If you replace a symbol by @, you do it by just removing the symbol. This is useful because in some cases it is difficult to end the replacement process without using this trick.

So, the language described by a grammar is the set of all strings you can produce with the production rules. If a string cannot in any way be produced by using the rules the string is not allowed in the language

OK. Now you know what BNF and EBNF are, what they are used for, but perhaps not why they are useful or how you can take advantage of them.

The most obvious way of using a formal grammar has already been mentioned in passing: once you\'ve given a formal grammar for your language you have completely defined it. There can be no further disagreement on what is allowed in the language and what is not. This is extremely useful because a syntax description in ordinary prose is much more verbose and open to different interpretations.

Another benefit is this: formal grammars are mathematical creatures and can be \"understood\" by computers. There are actually lots of programs that can be given (E)BNF grammars as input and automatically produce code for parsers for the given grammar. In fact, this is the most common way to produce a compiler: by using a so-called compiler-compiler that takes a grammar as input and produces parser code in some programming language.

Of course, compilers do much more checking than just grammar checking (such as type checking) and they also produce code. None of these things are described in an (E)BNF grammar, so compiler-compilers usually have a special syntax for associating code snippets (called actions) with the different productions in the grammar.

The best-known compiler-compiler is YACC (Yet Another Compiler Compiler), which produces C code, but others exist for C++, Java, Python as well as many other languages.

Parsing

They read symbols of some alphabet from their input.
Hint: The alphabet doesn\'t necessarily have to be of letters. But it has to be of symbols which are atomic for the language understood by parser/lexer.
Symbols for the lexer: ASCII characters.
Symbols for the parser: the particular tokens, which are terminal symbols of their grammar.
They analyse these symbols and try to match them with the grammar of the language they understood.
And here\'s where the real difference usually lies. See below for more.
Grammar understood by lexers: regular grammar (Chomsky\'s level 3).
Grammar understood by parsers: context-free grammar (Chomsky\'s level 2).
They attach semantics (meaning) to the language pieces they find.
Lexers attach meaning by classifying lexemes (strings of symbols from the input) as the particular tokens. E.g. All these lexemes: *, ==, <=, ^ will be classified as \"operator\" token by the C/C++ lexer.
Parsers attach meaning by classifying strings of tokens from the input (sentences) as the particular nonterminals and building the parse tree. E.g. all these token strings: [number][operator][number], [id][operator][id], [id][operator][number][operator][number] will be classified as \"expression\" nonterminal by the C/C++ parser.
They can attach some additional meaning (data) to the recognized elements. E.g. when a lexer recognizes a character sequence constituting a proper number, it can convert it to its binary value and store with the \"number\" token. Similarly, when a parser recognize an expression, it can compute its value and store with the \"expression\" node of the syntax tree.
They all produce on their output a proper sentences of the language they recognize.
Lexers produce tokens, which are sentences of the regular language they recognize. Each token can have an inner syntax (though level 3, not level 2), but that doesn\'t matter for the output data and for the one which reads them.
Parsers produce syntax trees, which are representations of sentences of the context-free language they recognize. Usually it\'s only one big tree for the whole document/source file, because the whole document/source file is a proper sentence for them. But there aren\'t any reasons why parser couldn\'t produce a series of syntax trees on its output. E.g. it could be a parser which recognizes SGML tags sticked into plain-text. So it\'ll tokenize the SGML document into a series of tokens: [TXT][TAG][TAG][TXT][TAG][TXT]....
