Write out the Logic Equation for each outputA0A1V of the fou

Write out the Logic Equation for each output(A_0,A_1,V) of the four input pricrity encoder below b. Obtain a truth table for gate 4 c. Obtain the truth table for gate 5

Solution

gate4

d3 d2 output(2 pin or gate)

0 0 0

0 1 1

1 0 1

1 1 1

D0 D1 D2 D3 gate5(i/p)

0 0 0 0 0

0 1 0 0 1

1 0 1 0 1

0 0 0 1 1

1 1 1 1 1

0 0 1 1 1

1 0 1 1 1
