rere following program, answer the following questions if the radius of the work 45 mm and we used radius programming 20 N5 G21 N10 G50 X200 Z200 N20 M03 S1000 N25 G00 X45 Z-30 N30 G01 X40 F.01. N35 G01 Z-60 N40 G01 X45 N45 G28 X50 Z5 N50 M05 N105 M30 1. Is this CNC ng program or CNC turning program? 2. Explain your answer in the previous question by giving one reason 3. What is the depth of cut? 4. Determine the coordinates of the tool home position. 5. Determine the coordinates of the intermediate point. 6. Where is the zero reference point for this work piece? 7. Draw the shape that will result after the program has been run. Show thi end and center points with the direction being used.

Solution

1) CBC turning program

3) depth of cut is 30

2) M03 is clockwise spindle rotation
