For this circuit VTH 1 V K 2 mAV2 lembda 001 Vminus1 VDD

For this circuit, V_TH = 1 V K = 2 mA/V2 lembda = 001 V^minus1 V_DD = |V_ss| = 10 V C_1 = C_2 = infinity R_1 = 20 kOhm  R_2 = 20 kOhm I_bias = 2 mA Determine the gain v_o/v_in Determine the input and output resistance, R_in and R_0 What is maximum undistorted peak to peak output voltage?

Solution

b) input resistance=R₁R₂/(R₁+R₂)

R_IN=20*20/40

=10Kohm

output resistance=infinity
