A What is the purpose of split ring in a dc generaor or moto

A. What is the purpose of split ring in a dc generaor or motor?

B. If dc current flows through the inductor, inductor will become open circuit. Is this statement true or false? Justify your answer

C. Write down three applications of inductor.

Please help me ASAP and be as thorough as possible. Thanks!

Solution

A split ring makes the current change direction every half-rotation .they are useful for DC motors where the current has to change direction .

As the coil is moved mechanically, a generated current will be produced, as the coil is turning in a magnetic field. The current produced will be AC, and hence, a split ring is used to invert the output every half turn, similar to their purpose in a motor, however in this case, the split ring is converting AC current into DC current, the opposite to the case in a motor, thereby producing a DC output\'

----------------------------------------------------------------------------------------

inductor, also called a coil or reactor, is a passive two-terminal electrical component which resists changes in electric current passing through it. It consists of a conductor such as a wire, usually wound into a coil. Energy is stored in a magnetic field in the coil as long as current flows

applications:

filters:

electromagnets

automotive inductive cells

Transformers:

loud speakers

induction motors
