Thanks for the help just need to get this hw done i understo

Thanks for the help just need to get this hw done. i understood mechanical physica but this elcrto stuff confuses me i am trying to do it just dont know if its right.

Problem1.jpg - Photos -4 5012 202 RV 25 2 7 aWRITE THE 4 KIRCHHOFF vo RCHOFF VOLTAGE LOOP EQUATIOs SOLVE F 3 THIS INVOLvES A LOT OF WORK Y NawA,FIN WA Y A SCRKEN S NOT OF THAT SITE, I\'m Cortana. Ask me anything F3 11:50 PM 3/23/2016

Solution

2.

Immediately after switch A is closed ,the time constant is

T=RC=(10*10³)(100*10^-6)

T=1 s

In a RC circuit ,Voltage as a function of time is given by

V_C=V_max[1-e^-t/T]

V_C=10[1-e^-5/1]

V_C=9.93262 Volts

b)

Voltage across resistor

V_R =V-V_C =10-0.93262

V_R=0.06734 Volts

Current through resistor after 5 seconds is

I=V_R/R =0.06734/10*10³

I=6.734*10^-6A

c)

After switch A is opened and switch B is closed .Time Constant is

T=RC=50*10³*100*10^-6

T=5 sec

Discharging through capacitor as a function of time is given by

V_C=V_maxe^-t/T

V_C=10e^-2/5

V_C=6.703 Volts
