What specific type of chain is shown? In what kind of situation is it used? Identify this image. Under what conditions is it used? This is a cross section of what specific type of belt? What type of sprocket is shown? What specific type of chain is shown, and in what category is this chain?

Solution

Fig 1 showing rolleing chain that use in to transmit rotary power between shafts and bush roller chains are use as transmission chains.

Fig 2 showing roller chain and it is the type of chain drive most commonly used for transmission of mechanical power on many kinds of domestic, industrial and agricultural machinery, including conveyors, wire- and tube-drawing machines, printing presses, cars, motorcycles, and bicycles.

Fig 3 showing a V belt.

Fig 4 showing spur sprocket.

In fig 5 used chain is roller bused chain under category of transmission chain.
