According to DFMD which designs of the following pairs are better and why? Elaborate!:

Solution

3.1 Figure 2 is better for DFMD design

Figure 2 has aerodynamic shape

3.2 Figure 2 is better for DFMD by design

component are devided and easy to assemblt

3.3 Figure 1 is better for DFMD by design

Figure 2 has linear co ordinate system

3.4 Figure 1 is better for DFMD by design

Figure 1 has more part which are ditacheble
