Consider the full wave rectifier circuit shown below with a

Consider the full wave rectifier circuit shown below, with a large smoothing capacitance C-500uF placed in parallel with the load resistor R 2K0 and Vm-12 sin(ut)v. Assuming that the diodes are ideal what is the maximum value of the load voltage, and current. Ideal Vsino) V\" sin(of) n sin(or) Ideal Select one: O a. ½ = 1.2V, and 2-6mA, O by-12V, and /L = 3mA, O C. None of the choices. O d. VL = 1.2V, and = 3mA,

Solution

Ans : C.

IT is a full wave rectifier.

maximum load voltage = maximum value of applled voltege = 12 volt.

Maximum current = maximum voltage/ resistance. = 12/2000 = 6 milli ampere.
