The magnitudes and directions of three vector are shown the figure. The magnitude and direction of the resultant of these vectors are:

a) 22m & 555o

b) 6.731m & 512.144o

c) 8.375 m & 312.144o

d) 8.3.75 m & 47.856o

Solution

1st vector : 7 angle 45 deg

2nd vector : 10 angle 300 deg

3rd vector : 5 angle 210 deg

Resultant : X component = 7cos45 + 10 cos(360 -300) - 5cos30

= 5.619 units

Y component = 7sin45 - 10sin60 - 5sin30 = - 6.21 units

Resultant = sqrt(5.619^2 + 6.21^2) = 8.37

Angle = 2pi - tan^-1(6.21/5.619) = 312.14 deg

Option C
