Consider the network of Fig. 1(a). The first four columns of part (b) show the delay vectors received from the neighbors of router J. Suppose that J has measured or estimated its delay to its neighbors. A, I, H. and K. as 10, 6, 15, and 5 msec, respectively. Update the new routing label for J.

Solution

To reach A,
via A-10msec
via I-6+24=30
via H-15+20=31
via K-5+21=26
It takes 10msec to reach A via A

To reach B,
via A-10+12=20
via I-6+36=42
via H-15+31=46
via K-5+28=33
It takes 20msec to reach B via A

To reach C,
via A-10+25=35
via I-6+18=24
via H-15+19=34
via K-5+36=41
It takes 24msec to reach C via I

To reach D,
via A-10+40=50
via I-6+27=33
via H-15+8=23
via K-5+24=27
It takes 23msec to reach D via H

To reach E,
via A-10+14=24
via I-6+7=13
via H-15+30=45
via K-5+22=27
It takes 13msec to reach B via I

To reach F,
via A-10+23=33
via I-6+20=26
via H-15+19=34
via K-5+40=45
It takes 26msec to reach F via I

To reach G,
via A-10+18=28
via I-6+31=37
via H-15+6=21
via K-5+31=36
It takes 21msec to reach G via H

To reach H,
via A-10+17=27
via I-6+20=26
via H-15+0=15
via K-5+19=24
It takes 15sec to reach H via H

To reach I,
via A-10+21=31
via I-6+0=6
via H-15+14=29
via K-5+22=27
It takes 6msec to reach I via I

To reach J,
It takes 0msec to reach J

To reach K,
via A-10+24=34
via I-6+22=28
via H-15+22=37
via K-5+0=5
It takes 5msec to reach K via K

To reach L,
via A-10+29=39
via I-6+33=39
via H-15+9=24
via K-5+9=14
It takes 14msec to reach L via K

10	A
20	A
24	I
23	H
13	I
26	I
21	H
15	H
6	I
0	-
5	K
14	K
