Determine the magnitude F of the forces applied to the wrenches.

The couple moment acting on the pipe has a magnitude of 330 N?m

Express your answer to three significant figures and include the appropriate units.

Solution :

Here the moment applied to each wrench is the product of force and perpendicular distance

Hence moment = P*r

But r= 150 mm= 0.15 m

M= 330 N.m

Hence 330=0.15*P

Hence P= 2200 N
