The rigid beam is supported by the three suspender bars. Bars AB and EF are made of aluminum and bar CD made of steel. If each bar has a cross-sectional area of 450 mm^2 determine the maximum value of P if the allowable stress is (alpha_allow)_st = 200 MPa for the steel and (alpha_allow)_al 150 MPa for the aluminum. E_st 200 GPa, E_al = 70 GPa.

Solution

We will first calculate force in each bar

Given,crossectional area of each bar= 450 mm²

Allowable stress in bar of steel=200 MPA and allowable stree in aluminium bars=150 MPA

Now calculating force in each bar.let the force in each bar be P

Calculating force P in bar AB which is an aluminium bar

= stress in bar AB x crossectional area of barAB= 150 MPAx 450 mm²=150x10⁶ PA x450mm²

=150 N/mm²x450 mm²=67500 N

Force in Bar CD which is a steel bar

=stress in bar CD x crossectional area of bar CD= 200 MPA x 450 mm²=200x10⁶PAx 450 mm²

=200 N/mm²x 450 mm²=90000 N

Force in bar EF

stress in bar EF x crossectional area of bar EF= 150 MPAx 450 mm²=150x10⁶ PA x450mm²

=150 N/mm²x450 mm²=67500 N

Now as per the Force balance equation, the summation of forces F+F2+F3=67500+90000+67500=225000 N------(1)

As given in the diagram above, the summation of Forces is also given by=P+2P----------(2)

Equating the equation (1) and (2) above,

P+2P=225000

3P=225000

P=75000 Newtons.Thus value of force P=75000 N
